Specifications
| Case Form Factor | Mid-Tower | Mid-Tower | |
|---|---|---|---|
| Dimension (WxHxD) | 195 x 473 x 427 (mm) 18.6 x 16.8 x 7 (in) |
195 x 473 x 427 (mm) 18.6 x 16.8 x 7 (in) |
|
| Motherboard Support | Mini-ITX/Micro ATX/ATX | Mini-ITX/Micro ATX/ATX | |
| 5.25" Drive Bay | 1 | 1 | |
| 3.5" Drive Bay | 2 | 2 | |
| 2.5" Drive Bay | 2+2 (converted from 3.5" drive bays) | 2+2 (converted from 3.5" drive bays) | |
| I/O Panel | USB3.0 x 2/USB2.0 x 2/Mic x 1/Audio x 1 | USB3.0 x 1/USB2.0 x 1/Mic x 1/Audio x 1 | |
| Maximum Number of Fans | 5 max. | 6 max. | |
| Cooling System | Front | 120mm Fan x 2 | 120mm Fan x 2 |
| Top | 120mm Fan x 2 | 120mm Fan x 2 | |
| Rear | 120mm (Pre-installed) | 120mm (Pre-installed) | |
| Side | None | 200 /120 / 80 mm x 1 | |
| Water Cooling Support | Front | 240mm | 240mm |
| Top | 120mm | 120mm | |
| Rear | 120mm | 120mm | |
| Fan Pre-installed | Rear | 120mm | 120mm |
| Cable Management | Yes | Yes | |
| Expansion Slots | 7 | 7 | |
| Max. Graphics Card Length | 350mm / 12.8 (in) Horizontal graphics card slots are compatible with RTX 3090/3080/3070. |
350mm / 12.8 (in) Horizontal graphics card slots are compatible with RTX 3090/3080/3070. |
|
| Max. CPU Cooler Height | 155mm / 6.1 (in) | 155mm / 6.1 (in) | |
| Transparent Side Panel | Left side panel | None | |
| PSU | Standard ATX PS2 | Standard ATX PS2 | |
| Max. PSU Length | 200 mm / 7.9 (in) | 200 mm / 7.9 (in) | |
