| Case Specification |
| Dimensions |
376mm x185mm x 292mm |
| Form Factor |
Mini ITX |
| Materials |
Steel, Plastic, Mesh |
| Mainboard Support |
Mini DTX, Mini ITX, Max MB size: 244 x 226mm (L x H) |
| Front Access & Controls |
2x USB 3.2 Gen 1 Type-A, 1x 3.5mm Headset Jack (Audio+Mic) |
| Side Panel |
Steel |
|
| Expansion & Drive Bays |
| Expansion Slots |
3 |
| 5.25" |
0 |
| 3.5"/2.5" (convertible) |
1 |
| 2.5" |
2 (Max. 3) |
|
| Fan Support |
| Bottom |
2x 120mm (recommended slim fans for GPUs wider than 2.5 PCI slots) |
| Top |
2 x 120mm |
| Rear |
1x 92mm |
| Included Fan(s) |
1x 92mm 650-2300RPM PWM (SickleFlow) ,1x 120mm 650-1800RPM PWM (SickleFlow) |
|
| Radiator Support |
| Side |
≤ 120mm, 140mm, 240mm, 280mm, (max width 141mm, not compatible with vertical GPU installation) |
| Bottom |
≤ 120mm, 240mm, (recommended for custom loops only) |
|
| Clearance |
| Max GPU Length |
≤ 330 mm |
| Max CPU Height |
≤ 155 mm |
| PSU Support |
≤ 130 mm |
|
| Miscellaneous |
| Dust Filter |
Top, Bottom, Left side, Right side |
| UPC# |
884102079061 |
| Net Weight |
4.6 kg / 10.1 lbs |
| Gross Weight |
4.6 kg / 10.1 lbs |
| Warranty |
2 years |
|
