| main spec |
| Dimensions |
410 x 207 x 474 mm (DWH) |
| Form Factor |
Mid Tower |
| Materials |
Steel + Plastic + Glass |
| Mainboard Support |
ATX, Micro-ATX, ITX |
| Front Access & Controls |
Power, LED Control Button, 2 x USB 2.0, 1 x USB 3.0 , MIC/HD-AUDIO |
| Side Panel |
Tempered glass |
|
| Drive Bays |
| Expansion Slots |
7 |
| 3.5" / 2.5" |
2 / 1 |
| 2.5" |
2 |
|
| Fan Support |
| Front |
3 x 120 mm / 2 x 140 mm |
| Top |
2 x 120 mm |
| Power supply |
2 x120 mm |
| Rear |
1 x 120 mm |
| Included Fan(s) |
3 x 120 ARGB fans in front (AX51)
3 x 120 ARGB fans in front + 1 x 120mm ARGB fan in rear (AX51 Elite) |
|
| Radiator Support |
| Front |
120 / 140 / 240 / 280 / 360 mm |
| Rear |
120 mm |
|
| Clearance |
| Max GPU Length |
290 mm |
| Max CPU Cooler Height |
155 mm |
| Max PSU Length |
205 mm(with HDD)
330 mm(without HDD) |
|
| Miscellaneous |
| Dust Filter |
Top / Bottom |
| Net Weight |
4.4kg (AX51) / 4.97Kg (AX51 Elite) |
| Gross Weight |
5.3Kg (AX51) / 5.85Kg (AX51 Elite) |
| Warranty |
1 year |
| UPC# |
0-761345-10061-8 (AX51)
0-761345-10068-7 (AX51 Elite) |
|
