| Case Specification |
| Dimensions |
527x232x506mm (DWH) |
| Form Factor |
Mid Tower |
| Materials |
0.8 mm SPCC + Plastic |
| Mainboard Support |
E-ATX, ATX,Micro-ATX,ITX |
| Front Access & Controls |
USB3.0 x 2, USB2.0 x 2, MIC/AUDIO(HD), Power, Reset, Fan Speed Controller (High/Stop/Low) |
| Side Panel |
Sound-Dampening Panels |
|
| Expansion & Drive Bays |
| Expansion Slots |
8 |
| 5.25" |
1 |
| 3.5" /2.5" |
8 |
| 2.5" |
2 |
|
| Cooling Support |
| Front |
3 x 120mm or
2 x 140mm(Installed from inside only) |
| Rear |
1 x 120mm or 1 x 140mm |
| Included Fan(s) |
3 x 120mm in Front & 1 x 140mm fan in rear |
|
| Radiator Support |
| Front |
≤ 360mm |
| Rear |
≤ 140mm |
|
| Clearance |
| MB Tray Clearance |
≤ 25mm |
| Max GPU Length |
≤ 270mm (With HDD Tray)
≤ 450mm (W/o HDD Tray) |
| Max CPU Cooler Height |
≤ 180mm |
| PSU Support |
≤ 290mm |
|
| Miscellaneous |
| Warranty |
2 Years |
| Dust Filter |
Front/Bottom |
| Net Weight |
11.82 Kgs |
| Gross Weight |
13.24 Kgs |
| UPC# |
0-761345-81103-3 |
|
